Bore Pig™ Mini Earth Auger 900752
| ITEM | QTY | PART NO. | DESCRIPTION | STOCK NO. |
| 1 | 1 | 319696 | BOOM MINI EA W/A | |
| 2 | 1 | 319694 | MOTOR YOKE MINI EA W/A | |
| 3 | 1 | 319695 | CROSS YOKE MINI EA W/A | |
| 4 | 1 | 313756 | MOUNT DRIVE W/A | |
| 5 | 1 | 311614 | HUB MOTOR 1-5/8 TAPER 5-BOLT | |
| 6 | 1 | 319697 | PIN 1 X 11.44 W/HOLE Z | |
| 7 | 1 | 316026 | PIN 1 X 5 W/A | |
| 8 | 1 | 313776 | MOTOR 30 4K WHEEL 1.62 TAPER | |
| 9 | 2 | 313781 | HOSE 1/2 X 65 10MB-8FJX | |
| 10 | 1 | 300418 | KEY SQ 7/16 X 1 1/4 | |
| 11 | 4 | 37214 | NUT REV LOCK | 1/2 NC |
| 12 | 5 | 103970 | BOLT STUD 1/2 X 1 1/2 NF | |
| 13 | 5 | 103925 | NUT LUG 1/2 NF | |
| 14 | 4 | 13211 | BOLT HEX | 1/2 X 2 NC GR 5 |
| 15 | 1 | 13420 | BOLT HEX | 7/8 X 4-1/4 NC GR 5 |
| 16 | 1 | 33634 | WASHER LOCK | 7/8" |
| 17 | 1 | 36118 | NUT FULL HEX | 7/8 NC |
| 18 | 1 | 13802 | BOLT HEX | 1/4 X 1-3/4 NC GR 5 |
| 19 | 1 | 37210 | NUT REV LOCK | 1/4 NC |
| 20 | 1 | 13309 | BOLT HEX | 5/8 X 1-1/2 NC GR 5 |
| 21 | 1 | 37216 | NUT REV LOCK | 5/8 NC |
| 22 | 1 | 13107 | BOLT HEX | 3/8 X 1-1/4 NC GR 5 |
| 23 | 1 | 37212 | NUT REV LOCK | 3/8 NC |
| 24 | 1 | 202830 | WASHER FLAT | 3/8 X 1-3/4 X 1/8 Z |
| 25 | 1 | 400000 | MOUNT FRAME TORO MINI W/A | OPT MNT PKG 400540 |
| 26 | 1 | 400001 | MOUNT FRAME ASV MINI W/A | OPT MNT PKG 400541 |
| 27 | 1 | 400002 | MOUNT FRAME BC MINI W/A | OPT MNT PKG 400542 |
| 28 | 1 | 330622 | MOUNT FRAME AVANT MINI W/A | AVANT ADPT MNT PKG 330753 |
| 29 | 6 | 167011 | NUT FLG TOP LOCK 1/2 NC GR 8 YZ | OPT MNT PKG'S |
| 30 | 6 | 15209 | BOLT HEX 1/2 X 1-1/2 NC GR 8 | OPT MNT PKG'S |
| 31 | 2 | 62180 | RIVET 3/16 X 3/8 CLOSED(NOT SHOWN) | FOR SERIAL PLATE |
| 32 | 1 | 13105 | BOLT HEX | 3/8 X 1 NC GR 5 |
