Quick Finish™ 3-Point PTO Finishing Mower 920156

ITEM QTY PART NO. STOCK NO.
1 1 421503 DECK 90 W/A
19 1 421671 BELT 2B173 BANDED
20 1 421548 SPRING EXT 1.25 OD X 6.63
23 1 421516 BRACKET TENSIONER PAINTED (UNPNT 421558)
29 2 421670 PULLEY IDLER 9 X 2
31 3 421700 SPINDLE HUB ASSM FM
32 1 300251 KEY SQ 1/4 X 1
34 1 421669 PULLEY 2B X 8.75
39 3 421704 PULLEY 2B X 6.75
40 1 314049 CHAIN LINK 5/16 X 5 LINKS
41 8 330766 THREADED INSERT 3/8 X 16 UNC YZ
44 12 33630 WASHER LOCK 5/8"
46 2 33016 WASHER FLAT 5/8"
54 3 36306 NUT HEX FULL 3/8 NC GR 5
56 2 13311 BOLT HEX 5/8 X 2 NC GR 5
60 12 36314 NUT HEX FULL 5/8 NC GR 5
65 12 37213 NUT REV LOCK 7/16 NC GR 5
67 1 42114 BOLT J 3/8-16 X 3.75
69 12 15159 BOLT HEX 7/16 X 1-1/2 NC GR 8 YZ
71 1 13323 BOLT HEX 5/8 X 5 NC GR 5
ITEM QTY PART NO. DESCRIPTION STOCK NO.
11 10 421563 KNOB PLASTIC 3/8 THREAD
18 1 421564 GEARBOX RC27 1:2.8
25 2 421684 BRKT COVER 90 SIDE PAINTED (UNPNT 421666)
26 1 421685 BRKT COVER 90 MIDDLE PAINTED (UNPNT 421667)
44 12 33630 WASHER LOCK 5/8"
48 12 36314 NUT HEX FULL 5/8 NC GR 5
70 4 13310 BOLT HEX 5/8 X 1-3/4 NC GR 5
92 1 421694 DRIVELN CAT4 6T X 6T X 33 (FM 90)
ITEM QTY PART NO. DESCRIPTION STOCK NO.
6 1 421551 BUSHING 1.13 X .749 X 3.13 Z
14 1 421553 HOOK STORAGE DRVLN
21 2 421514 BRKT HITCH A FRAME PAINTED (UNPNT 421549)
22 1 421515 BRKT HITCH UPPER PAINTED (UNPNT 421552)
24 2 421673 BRKT HITCH LONG 84/90 PAINTED (UNPNT 421618)
44 12 33630 WASHER LOCK 5/8"
45 4 15310 BOLT HEX 5/8 X 1-3/4 NC GR 8 YZ
51 1 300167 PIN CLEVIS .75 X 3.5
52 1 37212 NUT REV LOCK 3/8 NC GR 5
53 1 13324 BOLT HEX 5/8 X 5-1/2 NC GR 5
54 3 36306 NUT HEX FULL 3/8 NC GR 5
55 3 200064 PIN CLIP #11 1/8 X 2-5/8
60 12 36314 NUT HEX FULL 5/8 NC GR 5
ITEM QTY PART NO. DESCRIPTION STOCK NO.
2 2 421510 CLEVIS HITCH LOWER W/A
3 2 421507 GAUGE ARM 90 W/A
4 4 421509 GAUGE WHEEL YOKE 90 W/A Z
7 12 421664 BUSHING 1.75 X 1.344 X 1 Z
8 8 421663 BUSHING 1.75 X 1.344 X .50 Z
9 8 421662 BUSHING 1.75 X 1.344 X .25 Z
10 6 104432 PIN LYNCH 7/16 X 1-3/4
12 4 421665 WHEEL 13 X 5 - 6 SMOOTH
15 8 421661 BUSHING NYLON GAUGE 90
27 2 300583 PIN 3-POINT CAT1 LOWER 7/8 X 5
35 1 320847 HOLDER MANUAL CANISTER
43 11 33626 WASHER LOCK 1/2"
47 8 15216 BOLT HEX 1/2 X 3-1/4 NC GR 8 YZ
49 8 36110 NUT HEX FULL 1/2 NC GR 5
55 3 200064 PIN CLIP #11 1/8 X 2-5/8
57 2 33006 WASHER FLAT 5/16"
58 4 13379 BOLT HEX 3/4 X 8 NC GR 5
61 2 37211 NUT REV LOCK 5/16 NC GR 5
62 2 13055 BOLT HEX 5/16 X 1 NC GR 5
63 4 33632 WASHER LOCK 3/4"
66 4 36316 NUT HEX FULL 3/4 NC GR 5
72 2 300853 PIN CLEVIS .75 X 2.5
ITEM QTY PART NO. DESCRIPTION STOCK NO.
5 3 421512 BLADE CARRIER 90 W/A
28 6 421672 BLADE MWR 90 CW SWING
30 6 421695 BLADE BOLT 90
43 11 33626 WASHER LOCK 1/2"
59 6 169889 NUT SLOTTED 3/4-16 UNF
64 6 65127 PIN COTTER 3/16 X 2
68 3 18916 BOLT HEX 1/2 X 2-1/2 UNF GR 8 YZ
ITEM QTY PART NO. DESCRIPTION STOCK NO.
16 2 421679 PLATE CHAIN 90 PNT (UNPNT 421678) CHAIN SHIELD PKG 421677
17 70 421569 CHAIN LINK 5/16 X 3 LINKS CHAIN SHIELD PKG 421677
38 2 421711 ROD .25 X 42.88 CHAIN SUPPORT 90 CHAIN SHIELD PKG 421677
50 8 21817 BOLT CARRIAGE 3/8 X 1 NC GR 5
52 8 37212 NUT REV LOCK 3/8 NC GR 5
ITEM QTY PART NO. DESCRIPTION STOCK NO.
13 2 421579 ROLLER 3.75 X 4.13 ROLLER PKG 421674
36 1 421714 PIN .63 X 9.75 W/HOLES Z ROLLER PKG 421674
37 1 421716 BRKT FRONT ROLLER 90 PNT(UNPNT 421715) ROLLER PKG 421674
42 2 421511 CLEVIS HITCH LOWER LONG W/A LONG CLEVIS PKG 421696
50 3 21817 BOLT CARRIAGE 3/8 X 1 NC GR 5
52 3 37212 NUT REV LOCK 3/8 NC GR 5
73 2 65105 PIN COTTER 5/32 X 1-1/2 ROLLER PKG 421674
421563 KNOB PLASTIC 3/8 X 1 NC STUD

421563 KNOB PLASTIC 3/8 X 1 NC STUD
421672 BLADE MWR 90 CW SWING

421672 BLADE MWR 90 CW SWING
13310 BOLT 5/8 X 1-3/4 NC GR 5

13310 BOLT 5/8 X 1-3/4 NC GR 5
13323 BOLT 5/8 X 5 NC GR 5

13323 BOLT 5/8 X 5 NC GR 5
15159 BOLT 7/16 X 1-1/2 NC GR 8 YZ

15159 BOLT 7/16 X 1-1/2 NC GR 8 YZ
15216 BOLT 1/2 X 3-1/4 NC GR 8 YZ

15216 BOLT 1/2 X 3-1/4 NC GR 8 YZ
15310 BOLT 5/8 X 1-3/4 NC GR 8 YZ

15310 BOLT 5/8 X 1-3/4 NC GR 8 YZ
18916 BOLT 1/2 X 2-1/2 UNF GR 8 YZ

18916 BOLT 1/2 X 2-1/2 UNF GR 8 YZ
42114 BOLT J 3/8 X 3-3/4 NC

42114 BOLT J 3/8 X 3-3/4 NC
300167 PIN CLEVIS .75 X 3.5

300167 PIN CLEVIS .75 X 3.5
300853 PIN CLEVIS .75 X 2.5

300853 PIN CLEVIS .75 X 2.5
314049 CHAIN LINK 5/16 X 5 LINKS

314049 CHAIN LINK 5/16 X 5 LINKS
320847 HOLDER MANUAL CANISTER 12.5 X 3.5

320847 HOLDER MANUAL CANISTER 12.5 X 3.5
330766 NUT CLINCH 3/8 UNC X .80

330766 NUT CLINCH 3/8 UNC X .80
421503 DECK 90 FM W/A

421503 DECK 90 FM W/A
421507 GAUGE ARM 90 W/A

421507 GAUGE ARM 90 W/A
421509 GAUGE WHEEL YOKE 90 W/A Z

421509 GAUGE WHEEL YOKE 90 W/A Z
421510 CLEVIS HITCH LOWER W/A

421510 CLEVIS HITCH LOWER W/A
421511 CLEVIS HITCH LOWER LONG W/A

421511 CLEVIS HITCH LOWER LONG W/A
421512 BLADE CARRIER 90 W/A

421512 BLADE CARRIER 90 W/A
421514 BRKT HITCH A FRAME PAINTED

421514 BRKT HITCH A FRAME PAINTED
421515 BRKT HITCH UPPER PAINTED

421515 BRKT HITCH UPPER PAINTED
421516 BRKT TENSIONER PAINTED

421516 BRKT TENSIONER PAINTED
421548 SPRING EXT 1.25 OD X 6.63

421548 SPRING EXT 1.25 OD X 6.63
