Razor Tooth™ Pavement Saw 901196 901182 901183

29 ITEM QTY PART NO. DESCRIPTION STOCK NO.
1 1 319300 MOUNT FRAME P‐SAW W/A
2 1 319301 FRAME SLIDER P‐SAW W/A
3 1 319302 FRAME MNT MOTOR P‐SAW W/A
4 1 319303 FRAME SHIELD P‐SAW W/A
5 2 319304 SHAFT GUIDE SLIDER W/A
6 1 319305 ARM GUIDE ROD W/A
7 4 319327 ROLLER CAST 5 X 1 X 2.75
8 1 320795 TOOL PICK REMOVAL ASPH/CONCRT MODEL 2.5 & 4.5 ONLY
1 314874 TOOL BIT REMOVER ASSEMBLY OBSOLETE
9 1 319328 BUSHING 3 X 1.27 X 1.5 Z REPLACED 319329
1 319329 BUSHING 3 X 1.27 X 1 PNTD OBSOLETE
10 1 319373 BUSHING OILITE 1 X 1.25 X 1.5
11 2 319372 PIN 1.5 X 2.56 GRS W/A
12 2 314057 PIN 1.25 X 4.00 W/A
13 2 319370 PIN 1.25 X 2.19 GRS W/A
14 2 33446 WASHER MB 1 10GA NARROW
15 1 311370 CYLINDER 2 X 10 B‐B DEPTH
16 2 65127 PIN COTTER 3/16 X 2
17 6 13107 BOLT HEX 3/8 X 1‐1/4 NC GR 5
18 2 37212 NUT REV LOCK 3/8 NC
19 2 37219 NUT REV LOCK 1 NC
20 8 15209 BOLT HEX 1/2 X 1‐1/2 NC GR 8 YZ
21 8 37214 NUT HEX 1/2 REV LOCK 1/2 NC
22 2 37217 NUT HEX 3/4 NC
23 1 13369 BOLT HEX 3/4 X 4 NC GR 5
24 1 13365 BOLT HEX 3/4 X 3 NC GR 5
25 2 13473 BOLT HEX 1 X 5 NC GR 5
26 1 317274 CYLINDER 2 X 24 SIDE SHIFT
27 3 19929 BOLT FLANGED 3/8 X 3/4 NC FLG
28 2 319451 BRKT SHIPPING PAVE/ROCK SAW
29 4 103880 WASHER LOCK 3/8”
30 4 33465 WASHER MB 1 1/4 14 GA NARROW QTY VARIES FOR SPACING
31 4 33475 WASHER MB 1 1/2 14 GA NARROW QTY VARIES FOR SPACING
32 1 318670 TOOL BIT PUNCH MODEL 1.5 X 9 ONLY
ITEM QTY PART NO. DESCRIPTION STOCK NO. STOCK NO.
318682 PKG ROTOR BLADE WHEEL HD 1.5 X 30 PS
319481 PKG ROTOR BLADE WHEEL 1.5 X 30 PS OBSOLETE
319482 PKG ROTOR BLADE WHEEL 2.5 X 30 PS
319483 PKG ROTOR BLADE WHEEL 4.5 X 30
1 1 318683 ROTOR BLADE WHEEL HD 1.5 X 30 W/A USED IN PKG 318682
1 319313 ROTOR BLADE WHEEL 1.5 X 30 W/A OBSOLETE USED IN PKG 319481
2 1 319316 ROTOR BLADE WHEEL 2.5 X 30 W/A USED IN PKG 319482
3 1 319317 ROTOR BLADE WHEEL 4.5 X 30 W/A USED IN PKG 319483
4 28 314828 TOOTH BULLET CP UTILITY (Standard) 925 & 945 REPLACEMENT PKG 319489
28 314829 TOOTH BULLET CP/RS ASPHALT 925 & 945 REPLACEMENT PKG 318905
28 314830 TOOTH BULLET CP/RS CONCRETE 925 & 945 REPLACEMENT PKG 318908
5 44 319453 TOOTH BULLET HD 14MM 915 REPLACEMENT PKG 318679
36 319453 TOOTH BULLET HD 14MM 915 REPLACEMENT PKG 319488 OBLT
36 317417 TOOTH BULLET INSERT 1.654 REPLACED BY 319453
6 1 319460 MOTOR ASSM
7 10 15307 BOLT HEX 5/8 X 1‐1/4 NC GR 8 YZ
ITEM QTY PART NO. DESCRIPTION STOCK NO.
26 1 317274 CYLINDER 2 X 24 SIDE SHIFT CYLINDER
29 1 319475 VALVE ASSM ROCK SAW 2 FUNC REPLACED 319473
1 319473 VALVE ASSM ROCK SAW 2 FUNC REPLACED BY 319475
30 4 201925 ADPT STR 8MB‐6MJ
31 2 311673 ADPT STR 6MB‐6MJ
32 2 319324 HOSE 3/8 X 36 6FJX‐6FJX90 CYL BASE TO PORT A ON BLOCK
ITEM QTY PART NO. DESCRIPTION STOCK NO.
15 1 311370 CYLINDER 2 X 10 B‐B DEPTH
29 1 319475 VALVE ASSM ROCK SAW 2 FUNC REPLACED 319473
1 319473 VALVE ASSM ROCK SAW 2 FUNC REPLACED BY 319475
30 2 201925 ADPT STR 8MB‐6MJ
39 2 201539 ADPT ELB 6MB‐6MJ‐90
40 2 319323 HOSE 3/8 X 110 6FJX‐6FJX90 CYL BASE TO PORT B ON BLOCK
ITEM QTY PART NO. DESCRIPTION STOCK NO.
6 1 319460 MOTOR ASSM
29 1 319475 VALVE ASSM ROCK SAW 2 FUNC REPLACED 319473
1 319473 VALVE ASSM ROCK SAW 2 FUNC REPLACED BY 319475
33 2 319364 HOSE 3/4 X 54 12FJX-12FJX-45 MOTOR PORT B TO BLOCK PORT P
2 319322 HOSE 3/4 X 60 12FJX‐12FJX OBSOLETE REPLACED BY 319364
34 1 330897 HOSE 1/2 X 130 8FJX-8FJX90 CD (REPLACED 319325)
1 319325 HOSE 3/8 X 130 6FJX‐6FJX90 CD (REPLACED BY 330897)
35 1 319476 ADPT STR 4MBPSS‐6MJ
36 1 314826 ADPT ELB 12MJ‐12FJ‐90 OBSOLETE (319473 VALVE ONLY)
37 1 330782 ADPT TEE 12MJ‐12MJ‐12FJX
38 2 103431 ADPT STR 12MB‐12MJ
70 1 330813 ADPT ELB 4FP-6FJX90 MOTOR
71 1 330859 ADPT STR 4MP-4FP CHECK MOTOR (NOT PART OF HOSE KIT)
72 1 330849 ADPT STR 4MBSSPP-8MJ CASE DRAIN TO MOTOR
ITEM QTY PART NO. DESCRIPTION STOCK NO.
29 1 319475 VALVE ASSM ROCK SAW 2 FUNC REPLACED 319473
1 319473 VALVE ASSM ROCK SAW 2 FUNC REPLACED BY 319475
36 1 314826 ADPT ELB 12MJ‐12FJ‐90
37 1 330782 ADPT TEE 12MJ‐12MJ‐12FJX
41 2 319312 HOSE 3/4 X 72 12FJX‐ 12FJX LEAD
ITEM QTY PART NO. DESCRIPTION STOCK NO.
319460 MOTOR ASSM 80/90W LUBE 21OZ
1 1 319461 MOTOR ASSM 11.07
2 1 319462 GEARBOX PSW50 4.35:1 REPLACED BY 319463
3 8 330789 NUT FLG M20-1.5 GR 10.9
4 1 319467 ADPT BREATHER 6BSPP
5 1 319991 ADPT SEAL 6BSPP
ITEM QTY PART NO. DESCRIPTION STOCK NO.
319475 VALVE ASSM ROCK SAW 2 FUNC REPLACED 319473
319473 VALVE ASSM ROCK SAW 2 FUNC OBLT REPLACED BY 319475
1 1 319474 VALVE ASSM ROCK SAW INLET-2
1 319470 VALVE ASSM ROCK SAW INLET 319473 VALVE ONLY
2 2 319471 VALVE ASSM ROCK SAW CYL SECTION
7 1 300982 VALVE CHECK 100PSI
8 1 300955 WASHER E‐COIL SPACER SP10
9 2 314899 COIL VALVE 12V ECOIL CP
10 1 300984 VALVE RELIEF 2000PSI
11 1 300985 VALVE RELIEF
12 1 300983 ADPT STR 12MB‐12MJ‐.10 ORIFICE
13 1 103431 ADPT STR 12MB‐12MJ
14 1 313141 ADPT STR 12MB‐12MJ CHECK
15 2 300987 VALVE CHECK 4PSI
16 1 300986 LOGIC ELEMENT PILOTED 70PSI
201539 ADPT ELB 6MB-6MJ-90

201539 ADPT ELB 6MB-6MJ-90
15307 BOLT 5/8 X 1-1/4 NC GR 8 YZ

15307 BOLT 5/8 X 1-1/4 NC GR 8 YZ
319327 ROLLER FORGED 5 X 1 X 2.75

319327 ROLLER FORGED 5 X 1 X 2.75
319476 ADPT STR 4MBSPP-6MJ

319476 ADPT STR 4MBSPP-6MJ
330859 ADPT STR 4MP-4FP CHECK 250PSI

330859 ADPT STR 4MP-4FP CHECK 250PSI
319482 PKG ROTOR BLADE WHEEL 2.5 X 30 PS

319482 PKG ROTOR BLADE WHEEL 2.5 X 30 PS
33446 WASHER MB 1 10 GA NARROW

33446 WASHER MB 1 10 GA NARROW
300955 WASHER E-COIL SPACER SP10

300955 WASHER E-COIL SPACER SP10
319453 TOOTH BULLET 14MM UTILITY

319453 TOOTH BULLET 14MM UTILITY
330813 ADPT ELB 4FP-6FJX-90

330813 ADPT ELB 4FP-6FJX-90
13473 BOLT 1 X 5 NC GR 5

13473 BOLT 1 X 5 NC GR 5
33475 WASHER MB 1 1/2 14 GA NARROW

33475 WASHER MB 1 1/2 14 GA NARROW
300987 VALVE CHECK #8 4PSI

300987 VALVE CHECK #8 4PSI
314826 ADPT ELB 12FJ-12MJ-90

314826 ADPT ELB 12FJ-12MJ-90
317274 CYLINDER 2 X 24 B-H

317274 CYLINDER 2 X 24 B-H
319301 FRAME SLIDER P-SAW W/A

319301 FRAME SLIDER P-SAW W/A
319316 ROTOR BLADE WHEEL 2.5 X 30 W/A

319316 ROTOR BLADE WHEEL 2.5 X 30 W/A
319322 HOSE 3/4 X 60 12FJX-12FJX

319322 HOSE 3/4 X 60 12FJX-12FJX
319323 HOSE 3/8 X 110 6FJX-6FJX90

319323 HOSE 3/8 X 110 6FJX-6FJX90
319328 BUSH 3 X 1.27 X 1.5 Z

319328 BUSH 3 X 1.27 X 1.5 Z
319373 BUSHING OILES 1 X 1.25 X 1.5

319373 BUSHING OILES 1 X 1.25 X 1.5
319475 VALVE ASSM ROCK SAW 2 FUNC-2

319475 VALVE ASSM ROCK SAW 2 FUNC-2
330782 ADPT TEE 12MJ-12MJ-12FJX

330782 ADPT TEE 12MJ-12MJ-12FJX
330789 NUT FLG M20-1.5 GR 10.9

330789 NUT FLG M20-1.5 GR 10.9
